| Voltage |
120 V AC |
| NEMA Rating |
3, 3R, 7BCD, 9EFG |
| Number of Wires |
2 |
| Number of Poles |
3 |
| NEMA Type |
5-20R |
| Amps |
20 A |
| Material |
Malleable Iron |
| Hz |
60 |
| Hub Style |
Feed-Thru |
| Standards |
cUL Listed, UL Listed |
| Mounting Box |
2 Gang, Malleable Iron |
| Finish |
Baked Gray Epoxy Clad Finish |
| Screws |
Stainless Steel |
| Includes Mounting Hardware |
Yes |
| For Environment |
Hazardous Location |
| NEMA Receptacle Configuration |
5-20R |
| Housing Material |
Malleable Iron |
| Hub Type |
Feed Through |
| Hazardous Location Specification |
Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2 |
| Horsepower Rating |
1 hp |
| Features |
Factory-Sealed |
| GFCI |
Yes |
| Number of Gangs |
2 |
| Circuit Breaker |
Yes |
| Voltage Rating |
125V AC |
| Housing Material Finish |
Epoxy Powder Coated |
| Resistance Properties |
Dust Ignition Proof, Explosion Proof |
| NEMA Enclosure Rating |
3, 3R, 3RX, 7BCD, 9FG |
| Current Rating |
20 A |
| Option Materials |
1- or 2-gang copperfree (4/10 of 1% max.) aluminum bodies and covers available. See catalog pages for details |
| Standard Materials |
Malleable iron body and covers. Nylon 6/6 handle. Corrosion resistant stainless steel nameplate mounting bracket (optional) |
| Nameplate Mounting Bracket |
Make circuit description/identification easy and eliminate costly field installation (drilling/tapping) to accommodate circuit identification nameplates by using our bracket accessory. See catalog. |
| NEC Certifications and Compliances |
Class I, Division 1 and 2, Groups C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 7CD, 9EFG |
| Standard Finishes |
Tumbler switches have a triple-coat finish (1) zinc electroplate, (2) chromate, and (3) epoxy powder coat |
