Appleton AMLGL7CG6BU Hazardous LED Lighting Fixture

Appleton AMLGL7CG6BU Hazardous LED Lighting Fixture

UPC: 781381602570 | Harmonization / Schedule B : 9405.42.6000

Country of Origin: Mexico | Shipping Weight: 31.815 lbs

$3,031.43 - $3,031.43
$3,031.43
$3,031.43 - $3,031.43
$3,031.43

Appleton Areamaster II LED floodlight for hazardous locations: an enclosed, gasketed aluminum luminaire on a yoke mount, with an impact-resistant clear glass lens and 5000 K cool white light.

Series Areamaster II (AMLG)
Light Source LED
Fixture Wattage 110 W
Lumens 15,000 lm
Color Temperature 5000 K
CRI 70
Average Life 60,000 hr
Replaces 250 to 400 W lamp fixtures
Input Voltage 120-277 VAC, 170-300 VDC
Housing Material Aluminum
Housing Finish Architectural bronze polyester coating
Lens Impact-resistant clear glass
Mounting Yoke
Enclosure Rating NEMA 3R/4/4X, IP66/IP67
Conduit Entries Two 3/4 in NPT
Surge Protection 6 kV
Gaskets High-temperature silicone rubber
Dimensions 16.28 in H x 12.94 in W x 5.05 in D
Standards UL 844/1598/8750; CSA C22.2 No. 250.0 and No. 137; ATEX; IECEx; RoHS
Country of Origin Mexico
