| Voltage |
600V AC |
| NEMA Rating |
3, 3R, 4, 4X |
| Amps |
60 A |
| Standards |
CSA Certified 025875, CSA Certified C22.2 No. 159, CSA Certified C22.2 No. 25, CSA Certified C22.2 No. 30, UL 1010 (UL 1203), UL 1682, UL 894, UL E10784 |
| Number of Wires |
3 |
| Number of Poles |
4 |
| Material |
Copperfree Aluminum |
| Features |
Auxiliary Contacts 1NO + 1NC, Special Polarization: Prevents Plug Insertion in a Receptacle or Connector Wired for a Different Voltage |
| Housing Material Finish |
Epoxy Coat with Powder Finish |
| Pin & Sleeve Standards |
CSA Certifications, UL 1682, UL Listed |
| For Environment |
Hazardous Location |
| Grounding |
Grounded |
| Compatible with Series |
FSQC |
| Phase |
Three |
| Hazardous Location Specification |
Class I, Div 1 and 2, Group B, C, D, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2 |
| Polarized |
Yes |
| Insulation Material |
Fiberglass-Reinforced Polyester |
| Current Rating |
60 A |
| Horsepower Rating |
30 hp |
| NEMA Enclosure Rating |
3, 3R, 4, 4X, 7CD, 9FG |
| Voltage Rating |
600V AC |
| Cap Type |
Screw-On Cap |
| Housing Material |
Metallic |
| Grounding Style |
Style 2 |
| Pin & Sleeve Standards` |
UL 1682 |
| Housing Color |
Gray |
| Switch Rated |
No |
| Reverse Service |
No |
| Connection Orientation |
Straight |
| Hazardous Area Classification |
Class I, Division 1 and 2, Groups B, C, D; Class II, Division 1 and 2, Groups F, G; Class III; NEMA 3, 3R, 4, 4X, 7CD, 9FG |
| Materials and Finishes |
Receptacles, mounting box, covers and plug housings are copperfree (4/10 of 1% max.) aluminum with epoxy powder coat. Insulating blocks are fiber glass reinforced polyester. |
| Amperage |
30, 60 or 100 |
| Mounting Box Entries |
Feed-Thru |
| Wire Range |
30 Amp: #10-#8, 60 Amp: #6-#4, 100 Amp: #2-1/0 |
