| Ball Material |
Brass |
| Max. Steam Pressure |
150 psi WSP |
| Temp. Range |
0 Degrees to 400 Degrees F |
| Handle Type |
Lever |
| Handle Material |
Plated Steel, PVC |
| Stem Material |
316 Stainless Steel |
| Compliance |
ARRA, CSA Certified B356, FM Approved, UL Listed |
| Port |
Full |
| Stem Type |
Blowout Resistant |
| Seat Material |
RPTFE |
| Valve Structure |
2-Piece |
| Features |
100% Factory Tested, Adjustable Stem Packing, Corrosion Resistant Materials, Heavy Pattern Forged Design, Silicone Free Assembly |
| Standards |
ARRA Compliant, Build America Buy America Act (BABA), Buy American Act (BAA), CSA B356, FM |
| Seal Material |
RPTFE |
| Connection Type |
FNPT x FNPT |
| Max. Pressure |
600 psi |
| Connection Gender - Side 2 |
Female |
| Maximum Pressure - Combustible Gas |
Not Rated |
| Maximum Pressure - Operating |
600 psi |
| Meets UL Flammable Gas and Liquid Standards |
UL 125, UL 1477, UL 842 |
| Manufacturer Warranty |
5 yr |
| Connection Type - Side 2 |
NPT |
| Handle - Locking |
Non-Locking |
| Vacuum Service Rating |
29 in Hg |
| Color - Valve Handle |
Yellow |
| Connection Gender - Side 1 |
Female |
| Valve Construction |
Two-Piece |
| Operating Temperature - Maximum |
400 Degrees F |
| Operating Temperature - Minimum |
0 Degrees F |
| Valve Body Style |
Straight |
| Cleaned and Bagged |
Not Cleaned and Bagged |
| For Media |
Steam |
| Valve Ways |
2-Way |
| Maximum Pressure - Steam |
150 psi |
| Connection Type - Side 1 |
NPT |
| Ball Port Style |
Full Port |
| 3-A Standard Compliance |
Not Rated |
| Color - Valve Body |
Bronze |
| Coefficient of Volume (Cv) |
0.01 |
| Valve Series |
77F |
