3M MNG18-47PX-A Pin Terminal, Red, Nylon, 0.075 in Pin Dia

3M MNG18-47PX-A Pin Terminal, Red, Nylon, 0.075 in Pin Dia

UPC: 051128588451 | Harmonization / Schedule B : 8536.90.4000

Country of Origin: Taiwan | Shipping Weight: 0.21 lbs

$246.32 - $246.32
$246.32
$246.32 - $246.32
$246.32

Pin Terminal, Contact Finish Tin, Contact Material Copper, Insulation Color Red, Insulation Coverage Partial Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Pin Diameter 0.075 in, Pin Length 0.47 in, RoHS Compliant Yes, Seam Style Butted, Standards CSA Certified, UL Listed, Termination Style Crimp, Barrel Inside Diameter 0.08 in, Barrel Outside Diameter 0.17 in

Maximum Wire Size 18 AWG
Minimum Wire Size 22 AWG
Overall Length 0.9 in
Pin Length (In.) 0.47
Barrel Inside Dia. 0.08 in
Pin Diameter 0.075 in
Barrel Inside Diameter 0.08 in
Pin Length 0.47 in
Barrel Outside Diameter 0.17 in
Stud Size 0.075 in
Wire Rope Length 0.9 in
Length 0.9 in
Terminal Shape Pin
Termination Style Crimp Termination Only
Insulation Color Red
Insulation Coverage Partial Coverage
Insulation Type Nylon
Contact Material Copper
Maximum Voltage 600 V
Minimum Operating Temperature -40 Degrees F
Maximum Operating Temperature 221 Degrees F
Standards CSA Certified, UL Listed
Wire Range 22 to 18 AWG
Max. Voltage 600 V
Terminal Connection Crimp
Max. Temp. 221 Degrees F
Seam Brazed
Connection Type Crimp
Connection Material Copper
Terminal Type Pin
Special Features Funnel-Designed, Seamless Brass Sleeve Offers Easy Insertion of Wires, Provides Quick Connection for Set Screws or Clamps That are Used to Make Electrical Contact
Compatible with Product Type Copper Wires
RoHS Compliant Yes
Seam Style Butted
Barrel Style Insulation Grip
Insulation Material Nylon
Contact Finish Tin
Insulation Dia 0.17 Inch
Country of Origin Taiwan, Province of China
