| Tape Color |
Gray |
| Series |
35 |
| Performance Temp. |
Up to 220 Degrees F |
| UPC |
054007000723
|
| Tape Tensile Strength |
17 lb/in |
| Color |
Gray |
| Standards |
ASTM, ASTM D1000, CSA, RoHS, RoHS 2002/95/EC, UL 510, VDE, VDE 0340-TEIL1 |
| Material |
Backing: Vinyl; Adhesive: Rubber Resin |
| Duct Tape Adhesive |
Rubber |
| Temperature Range |
32 to 220 Degrees F |
| Adhesion Strength |
20 oz./in. |
| Shape |
Continuous Roll |
| UV Resistance |
No |
| Max. Voltage |
600 |
| Tape Backing Material |
Vinyl |
| Duct Tape Grade |
Premium |
| Duct Tape Type |
PVC tape |
| Adhesion to Steel |
20 oz/in |
| Product Form |
Continuous Roll |
| Sub-Brand |
Scotch(R) |
| Breaking Strength |
17 lb/in |
| Environment |
Indoor/Outdoor |
| Self-extinguishing |
Not Self-Extinguishing |
| Maximum Tape Performance Temperature |
221 Degrees F |
| Adhesive Properties |
Aggressive Adhesive, Pressure Sensitive Adhesive |
| Tape Properties |
Pressure Sensitive Adhesive |
| Insulation Resistance |
1.00 x 10^6 megaohm |
| Tape Backing Construction |
Film |
| Minimum Tape Performance Temperature |
32 Degrees F |
| Specifications Met |
ASTM, CSA, RoHS, UL, VDE |
| Elongation |
225 % |
| Tape Brand |
3M(TM) |
| Tape Resistance Properties |
Abrasion-Resistant, Flame-Resistant, Moisture-Resistant, UV-Resistant |
| Tape Adhesive Format |
Single-Sided |
| Tape Adhesive Material |
Rubber |
| Tape Type |
Film |
| Tape Conformability |
Conformable at Low Temperature |
| Tape Sub-Type |
General Purpose |
| National Stock No. |
5970004822559 |
| Dielectric Strength |
1,250 V/mil |
| Printed Message |
Unprinted |
| Breakdown Voltage |
8,750 V |
| Voltage Rating |
600 V |
| Products By Industry |
Electrical |
