Tape Color |
Yellow |
Performance Temp. |
Up to 220 Degrees F |
Material |
Backing: Vinyl; Adhesive: Rubber Resin |
Tape Tensile Strength |
17 lb/in |
Tape Adhesive Strength |
20 oz/in |
Color |
Yellow |
Thickness |
7 mil |
Shape |
Continuous Roll |
Max. Tape Performance Temp. |
220 Degrees F |
Item |
Insulating Electrical Tape |
Duct Tape Adhesive |
Rubber |
Series |
35 |
Tape Adhesive |
Rubber |
Tape Backing Material |
Vinyl |
Temperature Range |
32 to 220 Degrees F |
Standards |
ASTM D1000, CSA Certified, RoHS 2002/95/EC, UL 510 |
Tensile Strength |
17 lb./in. |
Tape Shape |
Continuous Roll |
UV Resistance |
No |
Tape Thickness |
7 mil |
Tape Color Family |
Yellow |
Max. Voltage |
600 |
Adhesive |
Rubber |
Adhesion Strength |
20 oz./in. |
Environment |
Indoor and Outdoor |
Product Form |
Continuous Roll |
Printed Message |
Unprinted |
Elongation |
225 % |
Adhesive Properties |
Aggressive Adhesive, Pressure Sensitive Adhesive |
Voltage Rating |
600 V |
Tape Backing Construction |
Film |
Tape Adhesive Format |
Single-Sided |
Breakdown Voltage |
8,750 V |
Tape Type |
Film |
Adhesion to Steel |
20 oz/in |
Minimum Tape Performance Temperature |
32 Degrees F |
Tape Sub-Type |
General Purpose |
Tape Properties |
Flame-Retardant |
Tape Adhesive Material |
Rubber |
Self-extinguishing |
No |
Maximum Tape Performance Temperature |
221 Degrees F |
Insulation Resistance |
1.00 x 10^6 megaohm |
Tape Brand |
3M(TM) |
Sub-Brand |
Scotch(R) |
Tape Resistance Properties |
Abrasion-Resistant, Flame-Resistant, Moisture-Resistant, Solvents-Resistant, UV-Resistant |
Specifications Met |
ASTM, CSA, RoHS, UL |
Dielectric Strength |
1,250 V/mil |
Breaking Strength |
17 lb/in |
Self-Extinguishing |
No |
Brand |
3M(TM) |
Max Tape Performance Temp |
221 Degrees F |
