Ultra-Dex USA 957-000-105 Indexable Thread Turning Tool Holder, A12Q LSER3

Ultra-Dex USA 957-000-105 Indexable Thread Turning Tool Holder, A12Q LSER3

UPC: | Harmonization / Schedule B : 8466.10.0175

Country of Origin: United States | Shipping Weight: 0.7 lbs

$253.22 - $253.22
$253.22
$253.22 - $253.22
$253.22

Indexable Thread Turning Tool Holder, Insert Shape Triangle, Overall Length 7 in, A12Q LSER3, 0.5100 in, MTS-35 Insert Screw, Coolant Through, Laydown Threading, Right Hand

Shank Material High Speed Steel
Insert Shape Triangle
ANSI Code A12Q LSER3
Cutting Edge Type 0 Degrees
Style Solid, Coolant-Thru
For Use With 3IR
Rake Positive
Lead Angle 0 Degrees
ANSI Number A12Q LSER3
Min. Bore 0.935"
Left/Right Hand Right Hand
Inscribed Circle 3/8"
Mounting Style Screw Lock
Type Turning
Cutting Direction Right Hand
Cutting Application Laydown Threading
Center to Cutting Tip 0.5100 in
Insert Inscribed Circle 3/8 in
Coolant Fed Coolant Through
Insert Holding Type Screw On
Compatible Hardware MTS-35 Insert Screw
Number of Coolant Holes 1
Insert Style 3IR
ISO Number A12Q LSER3
Country of Origin United States
