| Insulated / Uninsulated |
Uninsulated |
| Capacity |
Up to 750 MCM Aluminum, Up to 900 MCM Copper |
| Max. Crimping Force |
30,864 lb |
| Primary Crimping Application |
Electrical Wire and Cable |
| Handle Material |
Fiberglass |
| Handle Type |
Fiberglass With Grips |
| Features |
Short Fiberglass Handle For Insulation and Ease of Use in Tight Spaces |
| For Use With |
Copper and Aluminum Lugs and Splices |
| Application |
Crimping Terminals/Splices/Disconnects |
| Adjustable |
Manual |
| Replacement Die Code |
None |
| Cuts |
No |
| Strips |
No |
| Insulated |
No |
| Compatible Terminal Type |
Crimping Terminal |
| Maximum Crimping Capacity - Aluminum Lug |
750 kcmil |
| Crimper Style |
Hydraulic Crimper |
| Includes Wire Stripper |
No |
| Minimum Crimping Capacity - Copper Lug |
8 AWG |
| Includes Wire Cutter |
No |
| Compatible Connector Type |
#8 - 900 kcmil copper lugs and splices, up to 750 kcmil aluminum |
| Adjustability |
Manual |
| Replacement Die Part Number |
None |
| Minimum Crimping Capacity - Aluminum Lug |
8 AWG |
| Includes Crimping Die |
No |
| Crimping Capacity - Aluminum Lug |
1/0 AWG, 2 AWG, 2/0 AWG, 250 kcmil, 3/0 AWG, 300 kcmil, 350 kcmil, 4 AWG, 4/0 AWG, 400 kcmil, 500 kcmil, 6 AWG, 600 kcmil, 750 kcmil, 8 AWG |
| Grip Style |
Deluxe Cushion |
| Maximum Crimping Force |
15 ton |
| Maximum Crimping Capacity - Copper Lug |
900 kcmil |
| Crimping Capacity - Copper Lug |
1 AWG, 1/0 AWG, 2 AWG, 2/0 AWG, 250 kcmil, 3/0 AWG, 300 kcmil, 350 kcmil, 4 AWG, 4/0 AWG, 400 kcmil, 500 kcmil, 6 AWG, 600 kcmil, 700 kcmil, 750 kcmil, 8 AWG, 900 kcmil |
| Crimping Capacity - Copper Lugs |
8 AWG - 900 kcmil |
| Grip Type - Insulated |
Non-Insulated |
| Compatible Connector |
Compression Lugs and Splices |
| Crimping Capacity - Aluminum Lugs |
8 AWG - 750 kcmil |
