| Sensing Element |
Bi-Metallic |
| Connection Location |
Back |
| Temp. Range (F) |
0 Degrees to 250 Degrees |
| Accuracy |
+/-1% |
| Window Material |
Glass |
| Stem Material |
304 Stainless Steel |
| Coil Finish |
Silicone Dampening |
| Temp. Range (C) |
-20 Degrees to 120 Degrees |
| Power Required |
No |
| Case Material |
304 Stainless Steel |
| Adjustments |
External |
| Case |
Stainless Steel |
| Includes NIST-Traceable Certificate |
No |
| Long Reach |
No |
| Scale Type |
Dial |
| Maximum Temperature C |
120 Degrees C |
| Thermometer Type |
Industrial Dial Thermometer |
| Vibration Resistant |
No |
| Case Features |
Hermetically Sealed |
| Thread Type |
NPT |
| Functions |
External Adjustment |
| Lead Free |
Yes |
| Housing Material |
304 Stainless Steel |
| Graduations |
2 Degrees F/2 Degrees C |
| Application |
Chemical and Petrochemical Plants, Equipment Skids, Food and Beverages, General Industrial, HVAC, Offshore Oil Rigs, Pharmaceutical/Biotech, Power, Pulp and Paper, Refineries, Water and Wastewater Pressure Control |
| Scale |
Celsius, Fahrenheit |
| Thread Gender |
Male |
| Process Connection |
1/2 in NPT |
| Shatterproof |
No |
| Lens Material |
Glass |
| Corrosion Resistant |
No |
| Minimum Temperature F |
0 Degrees F |
| Maximum Temperature F |
250 Degrees F |
| Construction |
304 Stainless Steel Housing and Stem with Glass Lens |
| Resistance Rating |
IP66, NEMA 4X |
| Glow-in-the-Dark |
No |
| Minimum Temperature C |
-20 Degrees C |
| Temperature Range |
0 Degrees to 250 Degrees F/-20 Degrees to 120 Degrees C |
| Maximum Operating Pressure |
Not Rated |
| Minimum Temperature °F |
0 Degrees F |
| Minimum Temperature °C |
-20 Degrees C |
| Maximum Temperature °C |
120 Degrees C |
| Maximum Temperature °F |
250 Degrees F |
