McMaster 9472K633 Oil - Resistant Aramid - Reinforced Buna - N Gasket with Bolt Holes, for 1 Pipe Size, ANSI Class 150 1/16 in thickness - KVM Tools Inc.KV9472K633 - 1/16

McMaster 9472K633 Oil-Resistant Aramid-Reinforced Buna-N Gasket with Bolt Holes, for 1 Pipe Size, ANSI Class 150 1/16 in thickness

UPC: | Harmonization / Schedule B : 4016.93.0000

Country of Origin: Mexico or United States | Shipping Weight: 1/16 in

$29.68 - $29.68
$29.68
$29.68 - $29.68
$29.68

These blended aramid fiber/Buna-N rubber gaskets resist oil, water, and aliphatic hydrocarbons such as ethylene. Commonly called full-face gaskets, they cover the entire face of flat-surface pipe flanges and align with the bolt holes.

Gaskets for ANSI class flanges are sized so all gasket specifications meet ANSI standards.

Gaskets for ANSI Class 150 flanges are compatible with low-pressure pipe flanges.

Shape

Ring with Bolt Holes
For Pipe Size

1
ID

1 5/16"
OD

4 1/4"
For Flange ANSI Class

150
Number of Bolt Holes

4
Maximum Pressure

1,000 psi
Temperature Range

-100° to 400° F
Hardness

Not Rated
Hardness Rating

Not Rated
Color

Blue
Material

Aramid Fiber/Buna-N Rubber Blend
Backing Type

Plain
Thickness

1/16 in.
RoHS

RoHS 3 (2015/863/EU) Compliant
REACH

REACH (EC 1907/2006) (06/27/2024, 241 SVHC) Compliant
DFARS

Specialty Metals COTS-Exempt
Country of Origin

Mexico or United States
USMCA Qualifying

No
Schedule B

401693.0000
ECCN

EAR99
