| Action Type |
Lever |
| For Media Type |
Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent |
| Max. Flow Rate |
20 gal per 100 strokes |
| Max. Viscosity |
1,500 SUS |
| Diesel Exhaust Fluid Compatible |
No |
| Wetted Materials |
301 Stainless Steel, Aluminum, Buna-N, PTFE, Zinc Plated Steel |
| Includes Suction Tube |
Yes |
| For Use With |
Ideal for Gasoline, Diesel Fuel, Light Oil and Kerosene |
| Discharge Tube Outlet ID |
3/4 in |
| Hose Tube Material |
Nitrile |
| Discharge Tube Outlet OD |
7/8 in |
| Features |
Flow Direction Can Be Reversed, Piston Action |
| Includes |
5/8 in x 8 ft. Hose with Static Ground Wire, Nozzle Spout 3/4 in |
| Self-Priming |
Yes |
| Agency Compliance |
UL Listed |
| Max. Flow GPM |
20 gpm |
| Seal Material |
Buna-N |
| Metered |
No |
| Suction Tube Material |
Steel |
| Piston Material |
Aluminum |
| Adapter Material |
Aluminum |
| Nozzle Operation |
Manual |
| Max. Fluid Temp. |
150 Degrees F |
| Compatible Chemicals |
Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, E85, Ethylene Glycol, Gasoline, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent |
| Discharge Connection Type |
FNPT |
| Includes Discharge Hose |
Yes |
| Pump Connection ID |
2 in |
| Pump Connection OD |
2 1/8 in |
| Power Source |
Hand Operated |
| Not Recommended Chemicals |
Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Ammonia (Liquids), Ammonium Hydroxide, Anhydrous Ammonia, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Cyclohexane, DEF, Deionized Water, Ethyl (Ethanol), Ethyl Acetate, Fertilizers, Formic Acid, Fresh Water, Fungicides, Heptane, Herbicides, Hexane, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Isopropyl (Isopropanol), Lacquer Thinners, Lithium Grease, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sodium Hypochlorite/Bleach (to 20%), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Trichlorethylene (50%), Turpentine, Windshield Washer Fluid, Xylene |
| Hose Cover Material |
Neoprene |
| Nozzle Material |
Aluminum |
| Food Grade |
No |
| Includes Nozzle |
Yes |
| Suction Tube OD |
1 in |
| Includes Bung Adapter |
Yes |
| Includes Spout |
No |
| Runs Dry |
Yes |
| Suction Tube ID |
1 in |
| For Container Type |
Drum |
| Max. Head Pressure |
50 psi |
| Min. Operating Temp. |
0 Degrees F |
| Max. Oil Flow |
25 oz per stroke |
| Max. Head - Pumps |
6 ft |
| Housing Material - Pumps |
Aluminum |
| Adapter Connection Type |
MNPT |
| Max. Outlet Pressure |
50 psi |
| Mount Type |
Bung |
