Apollo 94A10801 Manual Two-Way Ball Valve 2 in, Brass, Straight, FNPT x FNPT, 600 psi Max. Pressure (CWP)

Manual Two-Way Ball Valve, Body Material Brass, For Media Combustible Gases, Valve Construction Two-Piece, Nominal Valve Size 2 in, Valve Body Style Straight, 3-A Standard Compliance Not Rated, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 600 psi, Maximum Pressure - Steam Not Rated, Maximum Pressure - Combustible Gas Not Rated, Vacuum Service Rating Not Applicable, Ball Material Chrome-Plated Brass, Ball Port Style Full Port, Handle - Locking Non-Locking

Body Material	Brass
Connectoin Type	FNPT x FNPT
Body Style	Inline
Valve Design	2-Piece
Ball Valve Product Group	Manual
Port	Full
Temp. Range	0 Degrees to 400 Degrees F
Standards	CSA, UL
Stem Material	Brass
Features	General Purpose
Ball Material	Chrome Plated Brass
Seat Material	PTFE
Handle Type	Lever
Max. Pressure	600 psi CWP
UPC	670750823435
Ball Valve Basic Body Material	Brass
Handle Material	Steel with Corrosion Resistant Plating
Connection Type	FNPT x FNPT
Compliance	MSS SP-110
Valve Structure	2-Piece
Stem Type	Blowout Proof
Seal Material	EPDM
Connection	FNPT
Type	Two Piece
Connection Gender - Side 2	Female
Operating Temperature - Maximum	400 Degrees F
Handle - Locking	Non-Locking
Coefficient of Volume (Cv)	0
Manufacturer Warranty	2 yr
Valve Construction	Two-Piece
Cleaned and Bagged	Not Cleaned and Bagged
Connection Type - Side 1	NPT
Connection Type - Side 2	NPT
Maximum Pressure - Steam	Not Rated
Valve Body Style	Straight
Operating Temperature - Minimum	0 Degrees F
Maximum Pressure - Operating	600 psi
Valve Ways	2-Way
3-A Standard Compliance	Not Rated
Maximum Pressure - Combustible Gas	Not Rated
Connection Gender - Side 1	Female
Ball Port Style	Full Port
For Media	Combustible Gases
Color - Valve Handle	Yellow
Meets UL Flammable Gas and Liquid Standards	UL 125, UL 1477, UL 842
Valve Series	94A
