Flared Fitting Elbow, Fitting Material Brass, Flare Angle 45 Degrees , Application Natural Gases, LP Gases, Fitting Side A Connection Type Inverted Flare, Fitting Side B Connection Type FNPT, Fitting Side B Pipe Size 1/4 in, Fitting Side A Tube Outer Diameter 1/2 in, Fitting Thread Size 3/4 In.-16, Hex Size 3/4 in, Maximum Operating Pressure 750 psi, Maximum Operating Temperature 250 Degrees F, Overall Length 1 3/8 in, Specific Fitting Shape Straight Adapter, Standards SAE J512, SAE J513
| Tube Fitting Material |
Brass |
| Flare Type |
45 Degrees |
| Specific Fitting Shape |
Straight Adapter |
| Pipe Fitting Connection Type |
Flare x FNPT |
| Basic Pipe Fitting Material |
Metal |
| Basic Pipe Fitting Shape |
Adapter |
| Max. Pressure |
450 to 2800 psi |
| Specific Pipe Fitting Shape |
Adapter |
| Temp. Range |
-65 Degrees To 250 Degrees F |
| Maximum Operating Pressure |
750 psi |
| Fitting Side B Connection Type |
FNPT |
| Standards |
SAE J512, SAE J513 |
| Minimum Operating Temperature |
-65 Degrees F |
| Fitting Material |
Brass |
| Fitting Side A Connection Type |
Inverted Flare |
| Flare Angle |
45 Degrees |
| Application |
Natural Gases, LP Gases |
| Maximum Operating Temperature |
250 Degrees F |
| Compatible Tube Material |
Aluminum, Brass, Copper, Steel |
| Fitting Shape |
Straight |
| Operating Pressure - Maximum |
750 psi |
| Operating Temperature - Maximum |
250 Degrees F |
| For Media Type |
Gases |
| Operating Temperature - Minimum |
-65 Degrees F |
| Material Grade |
CA360 |
| Product Type |
Flared Fitting Adapter |
| Fitting Side 2 Connection Type |
FNPT |
| Connector Type |
Adapter |
| Fitting Features |
Rigid |
| Fitting Side 1 Connection Type |
Flared |
