| Wall Thickness |
1 in |
| Material |
Fiberglass |
| Insulation Nominal I.D. |
1 59/64 in |
| Approx. K Value |
0.16 |
| Insulation Type |
Hinged with Self Sealing Lap |
| Wall Thickness - Insulation |
1 in |
| Insulation Temp. Range |
0 Degrees F to 1000 Degrees F |
| Pipe Insulation Item |
Pipe Insulation |
| Insulation Approx. R Value |
6.4 |
| UPC |
047563710410 |
| Green Certification or Other Recognition |
GREENGUARD Certified |
| Insulation Approx. K Value |
0.16 |
| Temp. Range |
0 Degrees to 1000 Degrees F |
| Green Environmental Attribute |
Total VOC Emissions Less Than or Equal To 0.5 mg/m and Formaldehyde Emissions Less Than or Equal To 0.05 ppm |
| Insulation Body Material |
Fiberglass |
| Insulation Max. Thickness |
1" |
| Approx. R Value |
6.4 |
| Color |
Tan |
| Standards |
UL 723, ASTM E84 or CAN/ULC S-102-M, GREENGUARD, ASTM C 547; ASTM C 1136, Types 1-IV; ASTM C 795, MIL-I-22344D, Nuclear Regulatory Commission Guide 1.36, Non-Metallic Thermal Insulation; MIL-I-24244C (Ships); U.S. Coast Guard Approval No. 164.009; CAN/CGSB-51.9 - Type I, Class 2; New York City MEA No. 344-83; NFPA 90A; ASTM C411; ASTM C302; ASTM E96 (Procedure A) |
| Includes |
Pressure Sensitive Adhesive System |
| Smoke Developed Index |
50 |
| Installation Style |
Slit with Adhesive and Flap |
| K Value |
0.16 BTU |
| R Value |
6.4 |
| Sealing Method |
Adhesive Flap Seal |
| Green Environmental Properties |
Formaldehyde Less Than or Equal to 0.05 ppm, Total VOC Less Than or Equal to 0.5 mg/cu m |
| Jacket Color |
White |
| Tube Style |
Hinged |
| Plenum Rating |
Plenum Rated |
| Flame Spread Index |
25 |
