McMaster 5217K41 Automatic-Winding Hose Reel with Brass 3/8 NPT Female Inlet, for 75 Feet of Hose

Name: McMaster 5217K41 Automatic-Winding Hose Reel with Brass 3/8 NPT Female Inlet, for 75 Feet of Hose
Brand: McMaster-Carr
SKU: KV5217K41
Price: 1109.13 USD
Availability: InStock

UPC: | Harmonization / Schedule B : 8479.89.9900

Country of Origin: United States | Shipping Weight: 119 lbs

$1,109.13 - $1,109.13

$1,109.13

$1,109.13 - $1,109.13

$1,109.13

Quantity

These reels have more support than medium duty reels, so you can pull the hose out at an angle. Hose locks in place when pulled out; a quick tug causes it to retract. Connect your hose with NPT pipe threads to the reel outlet; connect your supply line to the reel inlet.

Pipe Size
Inlet	3/8
Outlet	3/8
Inlet
Fitting Material	Brass
Pipe Connection	Threaded NPT Female
Fitting Seal Type	Buna-N Rubber Gasket
Outlet Pipe Connection	Threaded NPT Female
For Hose
ID	3/8"
Maximum OD	11/16"
Length	75 ft.
Maximum Pressure	3,000 psi @ 72° F
Height	25 1/2"
Width	9 1/4"
Depth	23"
Material	Powder-Coated Steel
Mounting
Fasteners Included	No
Number of Holes	4
Hole Diameter	1/2"
Base Length	9"
Base Width	8"
Location	Ceiling, Floor, Wall
Support Bracket Thickness	1/4"
Temperature Range	-40° to 250° F
Color	Blue
Hose Included	No
Reel Type	Open
Winding Method	Automatic
RoHS	RoHS 3 (2015/863/EU) compliant with exemption 6(c) - Lead in copper alloy
REACH	Not Compliant
DFARS	Specialty Metals COTS-Exempt
Country of Origin	United States
USMCA Qualifying	No
Schedule B	847989.9900
ECCN	EAR99
