SKF NU 216 ECJ/C3 Cylindrical Roller Bearing, 216, 80 mm Bore, 140 mm OD, 26 mm Overall Wd, Steel, NU 216 ECJ/C3

SKF NU 216 ECJ/C3 Cylindrical Roller Bearing, 216, 80 mm Bore, 140 mm OD, 26 mm Overall Wd, Steel, NU 216 ECJ/C3

UPC: | Harmonization / Schedule B : 8482.50.0000

Country of Origin: | Shipping Weight: 3.507 lbs

$600.31 - $600.31
$600.31
$600.31 - $600.31
$600.31

Cylindrical Roller Bearing, Bearing Industry Number 216, Bore Diameter 80 mm, Bore Type Cylindrical, Cage Material Steel, Closure Open, Inner Ring Outside Diameter 121.691 mm, Maximum Speed 5,600 RPM, Maximum Temperature 300 Degrees F, Minimum Temperature -40 Degrees F, Number of Rows One, Outer Ring Inside Diameter 122 mm, Outside Diameter 140 mm, Overall Width 26 mm, Ring Material Alloy Steel, Roller Material Steel, Split Bearing Yes, System of Measurement Metric

Bore Dia. 80 mm
Outside Dia. 140
Width 26 mm
Outside Dia. Tolerance +0/-.018mm
Inner Ring Outside Dia. (In.) 3.976 in
Shoulder Height (mm) 129 mm
Outer Ring Inside Dia. (mm) 123 mm
Outer Ring Inside Dia. (In.) 4.8425 in
Inner Ring Outside Dia. (mm) 101 mm
Shoulder Height (In.) 5.0787 in
Shaft Fillet Radius 2 mm
Outside Diameter Tolerance +0.000/-0.018 mm
Overall Width 26 mm
Bore Diameter Tolerance +0.000/-0.015 mm
Bore Diameter 80 mm
Housing Fillet Radius 2 mm
Inner Ring Outside Diameter 121.691 mm
Outer Ring Inside Diameter 122 mm
Outside Diameter 140 mm
MFR # NU 216 ECJ/C3
Zoro # G7908713
UPC # -
Country of Origin Multiple
Roller Material Steel
Cage Material Steel
Static Load Capacity (Lb.) 37,300 lb
Dynamic Load Capacity (Lb.) 36,000 lb
Fillet Radii (In.) 0.0787 in
Type Open
Temp. Range (F) -40 Degrees to 300 Degrees F
Fillet Radii (mm) 2 mm
Tolerance +0/-.015mm
Static Radial Load Capacity 166 kN
Maximum Temperature 300 Degrees F
Split Bearing Yes
Full Complement No
Dynamic Radial Load Capacity 160 kN
Number of Outer Ring Flanges 2
Bearing Industry Number 216
Number of Inner Ring Flanges 0
Number of Rows One
System of Measurement Metric
Bore Type Cylindrical
Ring Material Alloy Steel
Minimum Temperature -40 Degrees F
Maximum Speed 5,600 RPM
Includes Retaining Ring No
Closure Open
Ring Material Grade 100Cr6
Industry Number 216
Country of Origin Varies (subject to change)
