Harrington NERM020L-L-20 Electric Chain Hoist H4 Heavy Duty, Motorized Trolley, 208-230/460V AC, 20 ft Lift Lg

Electric Chain Hoist, Duty Classification H4, Mount Type Motorized Trolley, Maximum Lifting Capacity 4,000 lb, Number of Speeds 1, Programmable Non-Programmable, Fixed Lift Speed 14 fpm, Minimum Lift Speed Not Applicable, Maximum Lift Speed Not Applicable, Trolley Speed 40 fpm, Maximum Lifting Length 20 ft, Current at Minimum Voltage 11.8 A, Current at Maximum Voltage 1.7 A, Motor Horsepower 2 3/8 hp, Operating Voltage 208-230/460V AC, Headroom 22 13/32 in, For Minimum Beam Height 4 29/32 in

Color	Yellow
Electric Hoist Item	Chain Hoist
Hoist Lift	20 ft
Hoist Mount	Motorized Trolley
Includes	Chain Container, Guardian Smart Brake, Motorized Trolley
Lift Speed	14 fpm
Load Capacity	4,000 lb
Min. Between Hooks	22 7/16 in
Motor HP	2.4 hp
Phase	3
Standards	ASME B30.16, UL 1340
Voltage	230/460
Number of Speeds	1
Clutch	Friction
Amps @ Low Volts	5.6 A
Thermal Protection	Yes
Trolley Speed	40 fpm
Item	Electric Chain Hoist
Finish	Electrostatic Enamel
Classification	H4
Control	110V Push Button Control Pendant
Lubrication	Oil Bath
Control Cord	16 ft
Fits Beam Flange W	3-7/32 in to 6-3/16 in
Brake	DC Current
Reeving	1
Trolley Configuration	Motorized Trolley
Features	Dual Speed Trolley VFD, Rubber Bumpers, Side Guide Rollers
Material	Aluminum Body
Number of Load Chains	1
Resistance Properties	Corrosion Resistant
Current at Max. Voltage	1.7 A
Includes Brake	Brake Included
Chain Material	Alloy Steel
Overload Protection Included	Yes
Hoist IP Rating	IP55
Starts and Stops per Hour	360
Trolley IP Rating	IP55
Trolley Wheel Material	Steel
Brake Type	DC Current
Clutch Type	Friction
Body Material	Aluminum
Lifting Hook Type	Swivel Hook with Safety Latch
Included Components	Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Rubber Bumpers, Safety Latch Hook
Motor Horsepower	2 3/8 hp
Controls	Push Button Pendant
Lifting Hook Material	Carbon Steel
Includes Clutch	Clutch Included
For Outdoor Use	Yes
Chain Grade	Grade 80
Duty Classification	H4
Body Finish	Enamel
Maximum Lifting Capacity	4,000 lb
Number of Reeves	1
Mount Type	Motorized Trolley
Fixed Lift Speed	14 fpm
Pendant IP Rating	IP65
Current at Min. Voltage	11.8 A
Programmable	Non-Programmable
Chain Finish	Nickel Plated
Headroom	22 13/32 in
Operating Voltage	208-230/460V AC
