| Type |
2-Port |
| Electrical Connections |
NEMA 5-15P Male Plug |
| Hose Connection |
1/4 in Male |
| Voltage |
100-240V AC |
| Motor HP |
1/2 hp |
| Operating Temp. Range (F) |
40 Degrees to 120 Degrees |
| For Use With |
HP and MP Blends, R-114, R-134A, R-22, R-401B, R-401C, R-402A, R-402B, R-404A, R-406A, R-407A, R-407B, R-407C, R-407D, R-408A, R-409A, R-410A, R-411A, R-411B, R-412A, R-507, R-509 |
| Requires |
Connection Hoses & Recovery Tank |
| Compressor |
Oilless |
| Weight (Lbs.) |
40.05 lb |
| Warranty |
1 yr |
| Liquid Recovery Rate - R-410A |
2 lb/min |
| Frequency |
60/50 Hz |
| Horsepower |
1/2 hp |
| Vapor Recovery Rate - General |
0.4 lb/min |
| For Refrigerant Type |
R-12, R-134A, R-22, R-407C, R-410A |
| Push/Pull Recovery Rate - R-22 |
12.8 lb/min |
| Hose Connection Gender |
Male |
| Vapor Recovery Rate - R-22 |
0.4 lb/min |
| Hose Connection Type |
SAE |
| Current |
12 A |
| Body Material |
Plastic |
| Capability |
Liquid, Push/Pull, Vapor |
| Calibration Certificate Type |
Not Certified |
| Power Source |
Plug-In |
| Includes Tank Overfill Switch |
Tank Overfill Switch Not Included |
| Weight |
32.9 lb |
| Low Pressure Cut-Off |
15 in Hg |
| Operating Temperature - Minimum |
40 Degrees F |
| Number of Ports |
2 |
| Hose Connection Thread Direction |
Right-Hand |
| A2L Compatibility |
A2L Compatible |
| Liquid Recovery Rate - R-22 |
2 lb/min |
| Push/Pull Recovery Rate - R-410A |
11.6 lb/min |
| NEMA Plug Configuration |
5-15P |
| Vapor Recovery Rate - R-410A |
0.4 lb/min |
| Liquid Recovery Rate - General |
2 lb/min |
| Push/Pull Recovery Rate - General |
12.8 lb/min |
| Series |
RecoverXLT |
| Compressor Type |
Oilless |
| High Pressure Cut-Off |
517 psi |
| Number of Cylinders |
2 |
| Standards |
UL to ARI 740-98 (ARI 740-95 for 95700 and 95765) |
| Product Type |
Refrigerant Recovery Machine |
| Operating Temperature - Maximum |
122 Degrees F |
| Motor Type |
Brushless DC |
| Mobility |
Handle |
