| Fan Voltage |
115V AC |
| Max. Ambient Temp. |
104 Degrees F |
| Motor RPM |
1,550 RPM |
| CFM @ 0.000-In. SP |
830 cfm |
| Exhaust/Supply Fan Item |
Exhaust Fan |
| CFM @ 0.125-In. SP |
440 cfm |
| Bearing Type |
Ball |
| Motor Enclosure |
Totally Enclosed Air Over |
| Motor Insulation |
Class B |
| Sones @ 0.000-In. SP @ 5 Ft. |
6.1 |
| Exhaust/Supply Fan Motor HP |
1/15 hp |
| Phase |
1 |
| Mounting Position |
Horizontal or Vertical |
| Thermal Protection |
Yes |
| Blade Material |
Aluminum |
| Operating Amps |
0.7 |
| Includes |
Intake Guard |
| Standards |
OSHA Compliant Guards |
| Guard Material |
Steel |
| Wire Guard Finish |
Black Powder Coated |
| Number of Blades |
3 |
| Mounting Holes O.C. |
10 1/4 in |
| Hz |
60 |
| Motor Type |
3-Phase |
| Frame Material |
Steel |
| Frame Finish |
Powder Coated |
| Ring-Mount Style |
Flange |
| Assembled |
Assembled |
| Noise Level @ 0.000 in SP @ 5 ft |
6.1 sones |
| Number of Fans |
1 |
| Guard Type |
Intake |
| Electrical Connection |
Hardwired |
| Full Load Current |
0.7 A |
| Motor Horsepower |
1/15 hp |
| Maximum Noise Level |
6.1 sones |
| Fan Style |
Guard-Mounted |
| Maximum Ambient Operating Temperature |
104 Degrees F |
| Housing Finish |
Powder-Coated |
| Exhaust Airflow @ 0.125 in SP |
440 cfm |
| Speed Controllable |
Yes |
| Mounting Orientation |
Horizontal, Vertical |
| Exhaust Airflow @ 0.100 in SP |
479 cfm |
| Wattage |
66 W |
| Frequency |
60 Hz |
| Nameplate Voltage |
115V AC |
| Housing Material |
Steel |
| Drive Type |
Direct Drive |
| Ventilation Type |
Exhaust |
| Motor Speed |
1,550 RPM |
| Includes Dehumidistat |
No |
| Guard Finish |
Powder Coated |
| Noise Level @ 0.100 in SP @ 5 ft |
6.04 sones |
| Maximum Coverage Area |
250 sq ft |
| Number of Speeds |
1 |
| Maximum Airflow |
830 cfm |
| Includes Motor |
Yes |
| Exhaust Airflow @ 0.000 in SP |
830 cfm |
