| CFM @ 0.100-In. SP |
71 |
| Drive Type |
Direct |
| Full Load Amps |
0.45 |
| Housing Material |
Steel |
| Includes |
Discharge Mounting Flange |
| Number of Speeds |
1 |
| Phase |
1 |
| Blower Item |
OEM Specialty Blower |
| Blower Outlet Shape |
Round |
| With Flange |
Yes |
| Blower Motor Type |
Permanent Split Capacitor |
| Blower Voltage |
115V AC |
| Blower Thermal Protection |
Auto |
| Blower Conduit Box |
Yes |
| Replaces |
4C443 |
| Housing Color |
Gray |
| Mounting Position |
All Position |
| CFM @ 0.300-In. SP |
66 |
| CFM @ 0.500-In. SP |
56 |
| Agency Compliance |
CE and RoHS Compliance, cULus Recognized (E47479) for the Motor Only Not the Blower |
| Housing Finish |
Enamel |
| Bearing Type |
Ball |
| Motor Insulation |
Class B |
| Hz |
50/60 |
| Item |
OEM Blower |
| CFM @ 0.000-In. SP |
75 |
| CFM @ 0.400-In. SP |
61 |
| Max. Ambient Temp. |
104 Degrees F |
| Max. Inlet Temp. |
104 Degrees F |
| RPM |
3016 |
| Wheel Type |
Forward Curve |
| Motor Enclosure |
Open |
| CFM @ 0.200-In. SP |
68 |
| Airflow @ 1.500 in SP Range |
More than 4000 cfm |
| Airflow @ 4.000 in SP |
Not Applicable |
| Speed Controllable |
No |
| High-Efficiency Motor |
No |
| Market |
Commercial, Industrial, Residential |
| Minimum Ambient Temperature |
-10 Degrees C |
| Airflow @ 11.00 in SP |
Not Applicable |
| Airflow @ 1.250 in SP |
Not Applicable |
| Sound Level |
Not Rated |
| Spark Resistant Construction Type |
Not Rated |
| Airflow @ 10.00 in SP |
Not Applicable |
| Wheel Material Finish |
Galvanized |
| Airflow @ 6.000 in SP |
Not Applicable |
| Airflow @ 4.500 in SP |
Not Applicable |
| Number of Inlets |
1 |
| Nominal Voltage |
115V AC |
| Hazardous Location Specification |
Not Applicable |
| For Air Type |
Clean Air |
| Motor Duty Class |
Continuous |
| Flange Type_broad |
Flanged Outlet |
| Mounting Orientation |
Multiposition |
| OEM Replacement |
Yes |
| Airflow @ 7.000 in SP |
Not Applicable |
| Motor Type |
Permanent Split Capacitor |
| Corrosion Resistant |
No |
| Includes Motor |
Yes |
| Airflow @ 0.750 in SP |
Not Applicable |
| Maximum Static Pressure |
1 1/8 in wc |
| Airflow @ 2.500 in SP Range |
More than 5000 cfm |
| Assembly |
Assembled |
| For Ventilation Type |
Exhaust, Make-Up, Return, Supply |
| Includes Drive Package |
Not Applicable |
| Brake Horsepower |
1/70 hp |
| Motor Speed |
3,020 RPM |
| Resistance Properties |
Corrosion Resistant |
| Mount Type |
All Position |
| Motor Enclosure Design |
Open |
| Motor IP Rating |
IP20 |
| Features |
Maintains cfm at Higher Static Pressures, Open Motors with Cast-Aluminum End Shields Dissipate Heat to Help Reduce Downtime and Extend Service Life |
| Electrical Connection |
Wire Leads |
| Chemical Resistant |
No |
| Outlet Shape |
Round |
| Discharge Position |
Bottom Horizontal, Down Blast, Top Horizontal, Up Blast |
| For High-Static Pressure Applications |
No |
| Frequency |
50/60 Hz |
| Flange Type |
Flanged |
| Housing Material Grade |
SPCC |
| Maximum Ambient Temperature |
104 Degrees F |
| Outlet Shape_broad |
Round |
| For Fan Speed (Dependent on Motor) |
0 RPM to 3,016 RPM |
| Airflow @ 1.500 in SP |
Not Applicable |
| Airflow @ 2.000 in SP |
Not Applicable |
| Airflow @ 3.500 in SP |
Not Applicable |
| Airflow @ 12.00 in SP |
Not Applicable |
| Airflow @ 8.000 in SP |
Not Applicable |
| Minimum Fan Speed |
0 RPM |
| Rotation |
CW |
| Thermal Overload Protection |
Yes |
| Airflow @ 0.000 in SP |
75 cfm |
| Airflow @ 13.00 in SP |
Not Applicable |
| Includes Mounting Hardware |
No |
| Application |
Air Conditioners, Air Cooling, Cooling, Drying, Component Cooling, General Heating, Machine Cooling, Space Ventilation, Ventilating |
| Airflow @ 1.000 in SP |
Not Applicable |
| Housing Material Finish |
Enamel |
| Airflow @ 0.100 in SP |
71 cfm |
| Maximum Fan Speed |
3,016 RPM |
| Maximum Inlet Air Temperature |
104 Degrees F |
| Airflow @ Static Pressures |
75 cfm @ 0.000 in SP / 68 cfm @ 0.250 in SP |
| Motor Frame Designation |
3.3" PSC Motor |
| Nameplate Voltage |
115V AC |
| Replacement For |
4C443 |
| Housing Material Gauge |
0.8 mm |
| Inlet Type |
Single-Inlet |
| Hazardous Location Application |
No |
| Airflow @ 9.000 in SP |
Not Applicable |
| Airflow @ 0.500 in SP Range |
0 to 999 cfm |
| AMCA Fan Class |
Not Rated |
| Current |
0.45 A |
| Standards |
CE and RoHS Compliance, cULus Recognized (E47479) for the Motor Only Not the Blower |
| Compatible Speed Control |
No |
| Airflow @ 3.000 in SP |
Not Applicable |
| For Location |
Indoor |
| Airflow @ 0.375 in SP |
Not Applicable |
| Motor Location |
Out of Airstream |
| Airflow @ 0.500 in SP |
56 cfm |
| Airflow @ 5.000 in SP |
Not Applicable |
| Motor Enclosure Design_Table |
Open Motor |
| Airflow @ 2.500 in SP |
Not Applicable |
| Material |
Steel Wheel & Steel Housing |
| Airflow @ 0.125 in SP |
Not Applicable |
| Airflow @ 0.400 in SP |
61 cfm |
| Motor Insulation Class |
B |
| Motor Horsepower |
1/70 hp |
| Airflow @ 0.250 in SP |
68 cfm |
| Wheel Material |
Steel |
| Package Quantity |
1 |
