NTN UCPX-2.7/16M Pillow Block Bearing 2-7/16 in Bore Cast Iron

NTN UCPX-2.7/16M Pillow Block Bearing, 2-7/16 in Bore, Cast Iron, Set Screw Locking, Ball Insert

UPC: | Harmonization / Schedule B : 8483.20.4040

Country of Origin: Japan | Shipping Weight: 16.48 lbs

$646.61 - $646.61
$646.61
$646.61 - $646.61
$646.61

Pillow Block Bearing, Base Height 1.063 in, Base Width 2.842 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 2 7/16 in, Bore Type Cylindrical, Center Height 2 63/64 in, Closure Open, Housing Material Cast Iron, Lubricant Material NLGI #3 Equivalent, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Mount Hole Center-to-Center Length 8 in, Mount Type Bolt-Through, Number of Mount Holes 2, Overall Height 6.063 in, Overall Length 10.468 in

System of Measurement Inch
Shaft Locking Type Set Screw
Housing Material Cast Iron
Bearing Material 52100 Chrome Steel
Bearing Insert Type Ball
Bearing Insert Material Alloy Steel
Series Medium Duty
Closure Open
Temp. Range -20 Degrees to 250 Degrees F
Finish Black Oxide
Lubricant Material NLGI #3 Equivalent
Mount Type Bolt-Through
Seal Type Contact
Minimum Temperature -40 Degrees F
Seal Material Nitrile Rubber
Bearing Material Grade 52100
Bore Type Cylindrical
Maximum Temperature 250 Degrees F
Dynamic Radial Load Capacity 13,938 lbf
Static Radial Load Capacity 9,892 lbf
Number of Mount Holes 2
Country of Origin Japan
