Baldor EM31155 2 HP ODP Motor

Baldor EM31155 General Purpose Motor, 2 HP, 230/460V AC, Open Drip Proof, Rigid Base Mount, 3450 rpm, 56 Frame

UPC: | Harmonization / Schedule B : 8501.52.4000

Country of Origin: United States | Shipping Weight: 43.35 lbs

$1,072.43 - $1,072.43
$1,072.43
$1,072.43 - $1,072.43
$1,072.43

NEMA 56 frame three-phase general purpose AC motors have a standard 5/8" diameter, 1-7/8" length shaft whose center is 3-1/2" above the base mounting surface. Variations to the frame's standard dimensions and design are indicated by a letter designation following the frame number, such as 56HZ or 56C. The letter “H” indicates that the frame has a set of mounting holes at 3" and 5", “Z” indicates that the frame has a nonstandard shaft, and “C” indicates that the motor can be face mounted. These frame standards and letter designations are defined by the National Electrical Manufacturers Association (NEMA).

HP 2
Phase Three
Voltage 230V AC; 460V AC
Full Load Amps 2.6/5.2/5.6 A
Frame 56
Nameplate RPM 3,450
Hz 60 Hz
Motor Service Factor 1.15
Insulation Class F
NEMA Design B
Motor Enclosure Design Open Drip Proof
Motor Mounting Type Rigid Base
Inverter Rated Yes
Motor Frame Material Steel
Shaft Dia. 5/8 in
Shaft Length 1-7/8 in
Overall Length 12-1/16 in
Nominal Efficiency 85.5 %
Standards CURUS; EEV; RoHS Compliant
Country of Origin United States
