McMaster 98350A490 Cotter Pin Zinc-Plated Spring Steel, 5 mm Diameter, 63 mm Long

UPC: | Harmonization / Schedule B : 7318.24.0000

Country of Origin: Germany | Shipping Weight: 0.051 lbs

Original price $52.15 - Original price $52.15
Original price
$52.15
$52.15 - $52.15
Current price $52.15

Lock the ends of clevis pins and shafts to keep components in place. Slide these cotter pins into a hole and then bend the prongs outward with pliers to secure. Also known as split pins, one prong is slightly longer than the other for easy opening once inserted. Repeated bending will weaken the pin, so they should not be reused.

Zinc-Plated Spring SteelThese pins withstand occasional exposure to moisture. However, since friction from moving parts can wear away the finish, they're not ideal for wet environments. While not nearly as corrosion resistant as stainless steel, they are stronger and won’t deform under stress.

Cotter Pin Type

Standard

Material

Zinc-Plated Spring Steel

Diameter

5 mm

Length

63 mm

Specifications Met

DIN 94, ISO 1234

Pin Type

Cotter

System of Measurement

Metric

Country of Origin

Germany

DFARS Compliance

Specialty Metals COTS-Exempt

Export Control Classification Number (ECCN)

EAR99

REACH Compliance

Not Compliant

RoHS Compliance

RoHS 3 (2015/863/EU) Compliant with Exemptions

RoHS Exemptions

6(a)

Schedule B Number

731824.0000

U.S.–Mexico–Canada Agreement (USMCA) Qualifying

No
