| Basic Actuator Style - Limit Switch |
Plunger |
| Actuator Style - Limit Switch |
Plunger, Spring Return |
| Contact Form- Switches |
2NC/2NO |
| Actuator Location - Limit Switch |
Top |
| AC Contact Rating - Limit Switch |
10A @ 600V |
| DC Contact Rating - Limit Switch |
10A @ 600V |
| Body Style - Limit Switch |
Standard |
| Mounting - Limit Switch |
Surface |
| Voltage Rating |
600VAC/DC |
| Actuator Location (Limit Switch) |
Top |
| Basic Actuator Style (Limit Switch) |
Plunger |
| Travel |
0.25 in |
| Limit Switch Style |
Hazardous Location Limit Switch |
| DC Contact Rating |
10A @ 600V |
| Body Material |
Aluminum |
| Operating Temp. Range |
0 Degrees to 185 Degrees F |
| NEMA Rating |
1, 12, 13, 2, 4, 6, 6P, 7, 9 |
| Movement |
Vertical |
| Mounting Hole - Limit Switch |
(2) 0.20 in dia |
| Stem Thread - Limit Switch |
No Stem |
| Actuator Style (Limit Switch) |
Plunger |
| Wiring Entry |
1/2 in NPT |
| Mounting Hole Spacing - Limit Switch |
2.35 in x 1.17 in |
| Contact Form |
2NC/2NO |
| IP Rating |
67 |
| Boot Sealed Actuator (Limit Switch) |
No |
| Operating Force |
7.0 lb |
| AC Contact Rating |
10A @ 600V |
| Standards |
CSA, UL |
| Electrical Connection |
Screw Terminals |
| Mounting Hole Pattern - Limit Switch |
2 Hole Diagonal |
| Actuator Location |
Top |
| Boot Sealed Actuator - Limit Switch |
No |
| Certification |
UL Class I Groups B, C, D and Class II Groups E, F, G |
| Amps |
10 |
| Body Style (Limit Switch) |
Standard |
| Actuator Style |
Plunger |
| Series |
9007CR |
| Contact Form - Limit Switch |
2NC/2NO |
| Head Material |
zinc |
| Special Features |
vertical approach, vertical approach |
| Contact Material |
silver contacts |
| Mechanical Durability |
10000000 cycles |
| Head Type |
plunger head |
| Short Circuit Protection |
10 A CC non-time delay |
| Shock Resistance |
60 gn 9 ms IEC 60068-2-27 |
| Vibration Resistance |
25 gn 10-150 Hz)IEC 60068-2-6 |
| Weight |
2.5 lb(US) |
| Electrical Durability |
1000000 cycles |
| Contact Action |
snap action |
| Actuation Type |
on end |
| Directional Movement |
Linear |
| Number of Mounting Holes |
2 |
| Hazardous Location Specification |
Class I, Div 1, Group B, C, D, Class II, Div 1, Group E, F, G |
| Includes Actuator |
No Actuator Included |
| Operating Force - Maximum |
7 lbf |
| Mounting Hole Horizontal Center to Center Distance |
30 mm |
| Mounting Hole Vertical Center to Center Distance |
60 mm |
| NEMA Enclosure Rating |
1, 12, 13, 2, 4, 6, 6P |
| Pretravel |
0.08 in |
| Boot Sealed Actuator |
No Boot Included |
| Resistance Properties |
Shock Resistant, Vibration Resistant |
| Mounting Style |
Surface |
| Operating Temperature - Maximum |
185 Degrees F |
| Operating Temperature - Minimum |
-20 Degrees F |
| Number Of Poles |
2 |
