| Head Material |
Plastic |
| NEMA Rating |
1, 13, 2, 3, 4, 4X |
| Type of Operator |
Flush Button |
| Color |
Black |
| Number of Operators |
1 |
| Item |
Flush Push Button |
| Bezel Material |
Plastic |
| IP Rating |
IP66, IP69K |
| Standards |
Bureau Veritas, Class II IEC 60536, CSA C22.2 No.14, DNV, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, GL, IEC 50102, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C8201-1, JIS C8201-5-1, LROS, REACH Free of SVHC, RoHS, UL 508 |
| Accessory Group |
A |
| Basic Material |
Plastic |
| Features |
Visually Distinct at a Distance, Snap-Fit Assembly, Double Head |
| Series |
XB5 |
| Nema Degree Of Protection |
NEMA 13 || NEMA 4X |
| Station Name |
XALD 1 to 5 cut-outs || XALK 2 to 5 cut-outs |
| Shock Resistance |
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Ambient Air Temperature For Storage |
-40-70°C |
| Head Type |
standard |
| Device Presentation |
basic element |
| Product Or Component Type |
head for non-illuminated push-button |
| Mechanical Durability |
10000000 cycles |
| Ip Degree Of Protection |
IP66 IEC 60529 || IP67 || IP69 || IP69K |
| Protective Treatment |
TH |
| Device Short Name |
ZB5 |
| Overvoltage Category |
class II IEC 60536 |
| Operator Profile |
black flush, unmarked |
| Product Certifications |
CSA || LROS (Lloyds register of shipping) || DNV || UL Listed || GL || BV |
| Shape Of Signaling Unit Head |
round |
| Ambient Air Temperature For Operation |
-40-70°C |
| Ik Degree Of Protection |
IK03 IEC 50102 |
| Vibration Resistance |
5 gn 2-500 Hz)IEC 60068-2-6 |
| Resistance To High Pressure Washer |
7000000 Pa 55°C 0.1 m |
| Electrical Composition Code |
C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting |
| Operating Temperature - Maximum |
158 Degrees F |
| Head Color |
Black |
| Operating Temperature - Minimum |
-40 Degrees F |
| Operator Illumination |
Non-Illuminated |
| Hazardous Location Specification |
Not Rated |
| Operator Material |
Plastic |
| Push Button Style |
Flush |
| Resistance Properties |
Shock Resistant, Vibration Resistant |
| NEMA Enclosure Rating |
1, 12, 13, 2, 3, 3R, 4, 4X |
|
