| Voltage - Emergency Lighting and Exit Signs |
120/277 |
| Lamp Watts - Emergency Lighting and Exit Signs |
1.5 W |
| Input Voltage |
120/277V AC |
| Lighting Technology |
LED |
| Output Voltage |
3.6 V DC |
| Mounting |
Ceiling/Wall |
| Housing Material - Emergency Lighting and Exit Signs |
Plastic |
| Housing Color - Emergency Lighting and Exit Signs |
White |
| Housing Material |
Plastic |
| Battery Chemistry |
Nickel Cadmium |
| Number of Lamp Heads |
2 |
| Emergency Illumination Time - Emergency Lighting and Exit Signs |
90 min |
| Watts @ 90 Minutes |
2 W |
| Features |
Flame Retardant |
| Green Environmental Attribute |
Product Contributes To Reducing Energy Consumption |
| Head Lamps Adjustable |
No |
| Warranty |
2 yr |
| UPC |
191848035375 |
| Operating Temp. Range |
10 Degrees to 40 Degrees C |
| Bulb Technology |
LED |
| Includes |
Mounting Hardware |
| Standards |
California Energy Commission Title 20 section 1605.3, FCC, NFPA 101, NFPA 70, OSHA, UL 924 |
| Emergency Illumination Time |
90 min |
| Housing Color |
White |
| Series |
EU2L |
| Compliance Type |
None |
| Remote Capacity |
1.5 W |
| Lamp Wattage |
0.75 W |
| Diagnostic Testing Function |
Test Button |
| CA Title 20 Compliant |
Yes |
| Maximum Operating Temperature |
104 Degrees F |
| Emergency Wattage |
2 W |
| Compatible Guard |
ELA WG1 |
| Bulb Included |
Yes |
| Emergency Battery Backup |
Yes |
| Environmental Rating |
Damp Location Rated |
| Recommended Single Fixture Spacing |
10 ft |
| NEMA Rating |
Not Rated |
| Minimum Operating Temperature |
50 Degrees F |
| Lamp Head Shape |
Round |
| Self Diagnostics |
No |
| Remote Capable |
Yes |
| Adjustable Lamp Heads |
No |
| Battery Voltage |
3.6 V DC |
| Current |
0.07 A |
| IP Rating |
Not Rated |
