| Mounting |
Stem |
| For Use With |
Area Lighting, Billboard Lighting, Car Lot Lighting, Municipal Lighting, Parking Lot Lighting, Roadway Lighting, Security Lighting, Street Lighting |
| Voltage |
208 to 277V AC |
| Max. Wattage |
4,150 |
| Max. Incandescent Amps |
15 A |
| Max. Ballast Amps |
8.3 A |
| Foot Candles On |
1.0 to 5.0 |
| Foot Candles Off |
3 to 15 |
| Color |
White/Gray |
| Temp. Range |
-40 Degrees to 158 Degrees F |
| Includes |
Lock Nut, Washer Gasket |
| Contact Form |
SPST |
| Enclosure Type |
Raintight |
| Description/Special Features |
1/2 in Threaded with Light Level Shield with Built in Delay |
| Housing Material |
Polycarbonate |
| Setting |
Dusk to Dawn |
| Standards |
cCSAus, California Title 20, UL Listed |
| Packaging Applications |
Parking Lot Lighting; Landscape Lighting; Exterior Lighting; Pedestrian Pathway Lighting; Street Lighting |
| Photocontrol Style |
Stem Mount |
| Operating Temperature Min |
-40 °C |
| Application Compatibilities |
HID; Fluorescent; Incandescent |
| Magnetic Ballast Load Ratings |
8.3 A, 1700-2300 VA |
| Other Certifications |
Title 20 |
| Photocontrol Sensor Location |
Side |
| Operating Temperature Max |
158 °C |
| Tungsten Load Ratings |
15 A, 3100-4150 W |
| Magnetic Ballast Load Ratings Ranges |
8.3 A, 1700-2300 VA |
| Photocontrol Type |
Thermal |
| Activation On |
1 to 5 fc |
| Applications |
Outdoor Lighting Control |
| Tungsten Load Ratings Ranges |
15 A, 3100-4150 W |
| Sensor Time Delay |
30 sec to 90 sec |
| Fail Mode |
ON |
| Photocontrol Photocell Type |
Cadmium Sulfide |
| Cover Color |
Gray |
| CSA Certification |
cCSAus |
| Usage Environments |
Outdoor |
| Market |
Commercial; Residential; Industrial |
| Wiring Option |
Wire leads |
| Input Voltage Ranges |
208-277 VAC, 50/60 Hz |
| Activation Off |
3 to 15 fc |
| UL Certification |
UL |
| Solutions |
Comfort & Convenience; Energy Savings; Landscape; Lighting Control; Security; Panel Integrators |
| Photocontrol Switch Type |
Mechanical Bimetal |
| Expected Lifetime Years |
5 |
| Expected Lifetime Operations |
3650 |
| Photo Control Switch Type |
Mechanical Bimetal |
| Operating Temperature Min (°F) |
-40 |
| Tungsten Range(s) |
15 A, 3100-4150 W |
| Tungsten (NO) |
15 A, 3100-4150 W |
| Operating Temperature Max (°F) |
158 |
| Magnetic Ballast (NO) |
8.3 A, 1700-2300 VA |
| Features |
Cadmium Sulfide Photocell, Mechanical Bimetal Switch |
| Input Voltage Range(s) |
208-277 VAC, 50/60 Hz |
| Photocell Type |
Cadmium Sulfide |
| Magnetic Ballast Range(s) |
8.3 A, 1700-2300 VA |
| Operating Temperature Min (°F) |
-40 |
| Operating Temperature Max (°F) |
158 |
| Stem Thread Type |
NPSM |
| On Illumination - Maximum |
5 fc |
| Off Illumination - Maximum |
15 fc |
| Indoor/Outdoor Usage |
Outdoor |
| Wattage - Maximum |
4,150 W |
| Ballast Current - Maximum |
8.3 A |
| Operating Temperature - Minimum |
-40 Degrees F |
| Incandescent Current - Maximum |
15 A |
| Compatible Lighting |
Fluorescent, HID, Incandescent |
| Body Color |
Gray |
| Off Illumination - Minimum |
3 fc |
| AC Operating Voltage |
208-277V AC |
| Time Delay - Minimum |
30 sec |
| Time Delay - Maximum |
90 sec |
| Operating Temperature - Maximum |
158 Degrees F |
| On Illumination - Minimum |
1 fc |
| Mounting Style |
Stem |
