| Type |
Pin & Sleeve |
| Body Material - Pin and Sleeve |
Copper-Free Aluminum |
| Voltage |
600V AC/250V DC |
| Amps - Plugs and Receptacles |
30 A |
| Amps |
30 A |
| Receptacle Type |
Pin and Sleeve |
| Number of Poles |
3 |
| Phase |
Three |
| Number of Wires |
3 |
| Material |
Copper Free Aluminum with Electro Statically Applied Epoxy, Powder Finish |
| Grounding Style |
Style 2 |
| NEMA Rating |
4x |
| Standards |
CSA Certified LR111846, UL E10757 |
| Use With |
Suitable for Indoor Or Outdoor Use, Pulp & Paper Mills, Electrical Power Plants, Petrochemical Plants, Wastewater Treatment, Marine, Docks, Ports, Construction Sites, Breweries, ReNeries, Chemical Plants, Grain Facilities, Textile Manufacturing, Food Processing Facilities |
| Features |
Boxes Come with a Green Grounding Screw |
| Market |
Industrial |
| Current Rating |
30 A |
| For Environment |
Cold, Corrosive, Hazardous Location, Wet |
| NEMA Enclosure Rating |
4X |
| Wire Connection Type |
Spring Clamp Terminals |
| Shrouded |
Yes |
| Contact Material |
Brass |
| For Location |
Indoor, Outdoor |
| IP Rating |
Not Rated |
| Flange Type |
Flanged |
| Reverse Service |
No |
| Grounding |
Grounded |
| Power Indicating Light |
No |
| Voltage Rating |
600V AC/250V DC |
| Polarized |
Yes |
| Number of Gangs |
1 |
| Housing Material |
Copper-Free Aluminum |
| Cap Type |
Flip-Up and Screw Cap |
| Housing Color |
Gray |
| Connection Orientation |
Straight |
| Housing Material Finish |
Baked Powder Epoxy/Polyester Coated |
| Hz |
50-400 Hz |
| Frequency Rating |
50-400 Hz |
| Finish Type |
Baked Powder Epoxy/Polyester Finish |
| Amperage Rating |
30 A |
| Application |
Suitable for indoor or outdoor use. Applications include the wet, cold, hosedown, hazardous or corrosive areas in such industrial applications as:Pulp & Paper Mills, Electrical Power Plants, Petrochemical Plants, Wastewater Treatment, Marine, Docks, Ports, Construction Sites, Breweries, Reï¬neries, Chemical Plants, Grain Facilities , Textile Manufacturing, Food Processing Facilities |
| Series |
VersaMate |
| Style |
Style II |
