3M 1181 Conductive Electrical Tape Strips, 1 in x 2 in, PK100

3M 1181 Conductive Electrical Tape Strips, 1 in x 2 in, PK100

UPC: 888519083291 | Harmonization / Schedule B : 7409.19.9000

Country of Origin: Taiwan | Shipping Weight: 0.25 lbs

$124.88 - $124.88
$124.88
$124.88 - $124.88
$124.88

Conductive Electrical Tape, Tape Backing Material Copper Foil, 1 in, 2 in, Tape Color Copper, Tape Sub-Type General Purpose Foil, Tape Adhesive Material Acrylic, 2.6 mil, 3M(TM), 1181, Minimum Tape Performance Temperature -40 Degrees F, Maximum Tape Performance Temperature 266 Degrees F, Voltage Rating 600 V, Shielding Effectiveness 66 dB, Liner Included Liner Included, Product Form Pre-Cut, Tape Adhesive Format Single-Sided, Package Quantity 100

Tape Color Copper
Series 1181
Performance Temp. -40 Degrees to 130 Degrees C
Tape Tensile Strength 25 lb/in
Adhesion Strength 35 oz./in.
Shape Rectangle
Material Copper Foil
Standards RoHS 2011/65/EU, UL Listed
Number of Adhesive Sides 1
Minimum Tape Performance Temperature -40 Degrees F
Tape Sub-Type General Purpose Foil
Product Form Pre-Cut
Adhesion to Steel 35 oz/in
Elongation 5 %
Breaking Strength 25 lb/in
Liner Included Liner Included
Tape Properties Electrically Conductive, EMI-Shielding
Voltage Rating 600 V
Tape Resistance Properties Heat-Resistant, Oil-Resistant, Oxidation-Resistant, Solvent-Resistant
Adhesive Properties Conductive
Tape Type Conducting Electrical Tape
Shielding Effectiveness 66 dB
Tape Adhesive Material Acrylic
Maximum Tape Performance Temperature 266 Degrees F
Pre-Cut Shape Strip
Insulation Resistance 5.00 x 10^-3 ohm/sq
Country of Origin Taiwan, Province of China
