U.S Motors T13CM2J Capacitor-Start General Purpose Motor, 1/3 HP, 56 Frame, 115/208-230V AC Voltage

UPC: 786382040543 | Harmonization (Schedule B): 8501.40.4040

Original price $455.99 - Original price $455.99
Original price
$455.99 - $455.99
Current price $455.99

General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/3 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.6/3.3-3.0, 56 Frame, Usable @ 208V Yes, Usable @ 200V No, Hz 60, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Manual, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan-Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base, Motor Mounting Position All Angle

Item General Purpose Motor
Motor Enclosure Design Totally Enclosed Fan-Cooled
Motor Mounting Type Rigid Base
HP 1/3
Voltage 115/208-230V AC
Frame 56
Motor Thermal Protection Manual
Motor Service Factor 1.15
Voltage Compatibility 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Motor Application General Application
Motor Design Capacitor-Start
Nameplate RPM 1,725
Motor Shaft Rotation CW/CCW
Motor Mounting Position All Angle
Motor Frame Material Steel
Motor Shaft Design Keyed
Standards CSA, UL
Duty Continuous
Ins. Class B
Inverter Rated No
Nominal Efficiency 60.8 %
Motor Bearings Ball
CC Number CC030A
No. of Speeds 1
Max. Ambient Temp. 40 Degrees C
Hz 60
Full Load Amps 6.6/3.3-3.0
Phase Single
RPM Group 1701-1800
Usable @ 208V Yes
Usable @ 200V No
Duty Cycle Continuous
Weight 22 lb
Package Quantity 1
